Showing maps for the latest capture of each device type, click on a device name to see all maps for that device type. Click and drag rows to reorder them.
Maps are laid out left to right, top to bottom. ASN is 1-65536, RFC 1918 is 10.0.0.0/8 followed by 172.16.0.0/12 followed by 192.168.0.0/16 (each square is a /24), Source and Destination Ports are 1-65536.
Blue is inbound traffic, Red is outbound traffic, Green is mostly bidirectional traffic.
-
windows-laptop
Host: 192.168.1.208
Filename: windows-laptop-16-09-23.pcap
Packets: 244765
Time window: 3 hours
Left to right:
• Public ASN
• Private RFC 1918
• Source Ports
• Destination Ports
-
windows-laptop
Host: 192.168.1.208
Filename: windows-laptop-16-10-05.pcap
Packets: 492454
Time window: 8 hours
Left to right:
• Public ASN
• Private RFC 1918
• Source Ports
• Destination Ports
-
windows-laptop
Host: 192.168.1.208
Filename: windows-laptop-16-10-07.pcap
Packets: 262242
Time window: 3 hours
Left to right:
• Public ASN
• Private RFC 1918
• Source Ports
• Destination Ports
-
windows-laptop
Host: 192.168.1.208
Filename: windows-laptop-16-10-11.pcap
Packets: 1222079
Time window: 7 hours
Left to right:
• Public ASN
• Private RFC 1918
• Source Ports
• Destination Ports
-
windows-laptop
Host: 192.168.1.208
Filename: windows-laptop-16-10-12.pcap
Packets: 3069526
Time window: an hour
Left to right:
• Public ASN
• Private RFC 1918
• Source Ports
• Destination Ports
