Showing maps for the latest capture of each device type, click on a device name to see all maps for that device type. Click and drag rows to reorder them.

Maps are laid out left to right, top to bottom. ASN is 1-65536, RFC 1918 is 10.0.0.0/8 followed by 172.16.0.0/12 followed by 192.168.0.0/16 (each square is a /24), Source and Destination Ports are 1-65536.

Blue is inbound traffic, Red is outbound traffic, Green is mostly bidirectional traffic.

• windows-laptop
  Host: 192.168.1.208
  Filename: windows-laptop-16-10-12.pcap
  Packets: 3069526
  Time window: an hour

  Left to right:

   • Public ASN
   • Private RFC 1918
   • Source Ports
   • Destination Ports



• samsung-tablet
  Host: 192.168.1.239
  Filename: samsung-tablet-16-10-12.pcap
  Packets: 20613
  Time window: 14 hours

  Left to right:

   • Public ASN
   • Private RFC 1918
   • Source Ports
   • Destination Ports



• echo
  Host: 192.168.1.240
  Filename: echo-16-10-12.pcap
  Packets: 22273
  Time window: 14 hours

  Left to right:

   • Public ASN
   • Private RFC 1918
   • Source Ports
   • Destination Ports



• printer
  Host: 192.168.1.236
  Filename: printer-16-09-28.pcap
  Packets: 2573
  Time window: 23 hours

  Left to right:

   • Public ASN
   • Private RFC 1918
   • Source Ports
   • Destination Ports



• iphone
  Host: 192.168.1.228
  Filename: iphone-16-10-04.pcap
  Packets: 473
  Time window: 23 minutes

  Left to right:

   • Public ASN
   • Private RFC 1918
   • Source Ports
   • Destination Ports



• android-1
  Host: 192.168.1.180
  Filename: android-1-16-10-07.pcap
  Packets: 5450
  Time window: 2 hours

  Left to right:

   • Public ASN
   • Private RFC 1918
   • Source Ports
   • Destination Ports



• nestsmoke
  Host: 192.168.1.168
  Filename: nestsmoke-16-10-11.pcap
  Packets: 183
  Time window: 27 seconds

  Left to right:

   • Public ASN
   • Private RFC 1918
   • Source Ports
   • Destination Ports



• android-2
  Host: 192.168.1.248
  Filename: android-2-16-10-12.pcap
  Packets: 7814
  Time window: an hour

  Left to right:

   • Public ASN
   • Private RFC 1918
   • Source Ports
   • Destination Ports
